Operating system: Windows CE.Net 5.0 including Movicon X real
flexible •
Upwards compatible with WIN32/64 • Vector
grafics without limitation of avariables and objects •
STEP7 - OPC data import function •
Open architecture FDA 21 CFR, part 11 •
ActiveX, OPC client/server, ADO CE-DB, SMTP e-mail server TAPI
SAPI RAS including networking web server VBA script ( Visual
Basic for
application ) •
4 parallel communication drivers, PLC ststion addressing and PLC
bridge
function to other controllers or possible with client-server
Movicon X
development platfrom • Extensive
drivers and svmbols library included as a standard feature
• Xscale
520 MHZ processor 64 MB RAM
•
Unique universal mounting capability
Well-pipe-or panel-mount Uitra-slim design 90mm ( 3.5 in.)
deep • Secur
data recording
Large internal Flash memory Archiving to SD memory card •
8 software recording channels for
recording of: Up to 4 analog/digital inputs
Math function results Modbus TCP signals • Remote
access and data retrieval Ethernet connectivity •
Install into the harshest of process environments •
Choice of dosplays
Color TFT or monochrome options •
Quick and easy setup
on-line help and Windows-style menus
• Xscale 520 MHZ processor 64 MB
RAM
•
Ideal replacement for paper recorder
- simple, cost-effective solution • Robust
and convenient archive storage
- low cost, high reliability, SmarMedia and Compact Flash
options
- high copacity • secure
data recording
- internal Flash memory for 12 recording channels and logs
- compliant with 21 CFR Part ll •
Intuitive user interface
- dedicated tactile operator keys and Windows TM-
Style menus •
Unsurpassend environmental protection
- hosedown to IP66 and NEMA4X standards
• Bright
and clear display
- high contrast, thin film transistor ( TFT )
- colar screen 14cm ( 5.7 in. ) • Robust
and convenient archive storage
- low cost high reliabienty ( Smart Media and Compact Flash )
-
high capacity ( up to 128Mb )
- Flash options • Secure
data recording
- internal flash memory ( 8Mb ) for 12 recording channels and
logs
- no battery back-up required •
Intuitive user interface
- dedicated operator keys and touch-screen configuration
- Windows TM-style menus
- Menu-driven operation • PC configurable
- easy configuration via PC possible •
Unsurpassed environmental protection
-
hosedown to IP66 and NEMA 4x standards • Remote
monitoring / access
- Ethernet communications embedded web protocols/server
• Bright
and clear display
- high contrast, thin film transistor ( TFT )
- colar screen 31cm ( 12.1 in. ) • Robust
and convenient archive storage
- low cost high reliabienty ( Smart Media and Compact Flash )
-
high capacity ( up to 128Mb )
- Flash options • Secure
data recording
- internal flash memory ( 8Mb ) for 36 recording channels and
logs
- no battery back-up required •
Intuitive user interface
- dedicated operator keys and
Windows TM-style menus
- Menu-driven operation • PC configurable
- easy configuration via PC possible •
Unsurpassed environmental protection
-
hosedown to IP66 and NEMA 4x standards • Remote
monitoring / access
- Ethernet communications embedded web protocols/server
•
1 to 4 line channels •
1 to 3 line channels and one printer channel
for data recording and text printout •
Format 144 mm x 144 mm mounting depth 250 mm •
Combined recording table for roll chart ( 32 m ) or
fanfold chart ( 16 m ) • RS-485
interface •
Measuring channels eletrically isolated •
2 limit per measuring channel
•
1 to 4 line channels •
1 to 3 line channels and one printer channel
for data recording and text printout •
Format 144 mm x 144 mm mounting depth 250 mm •
Analog scale and digital display •
Free assignment of measurement inputs to recording system • 64m
roll chart •
Automatic paper take-up •
RS-485 interface •
Measuring channels electrically isolated •
3 limits per measuring channel
formonitoring of absolute value and gradient up to
3% h •
4 pulse inputs ( counter inputs ) •
4 virtual channels for mathematical functions •
Balancing with minimun and maximum calcution and averaging • Standby
with/without storage of the measured values •
4 event markers
•
6 measuring
channels •
Last point visible from the front •
With text printout •
Measuring channels electrically isolated and earth-free •
Format 144 mm x 144 mm. mounting depth 250mm •
Free assignment of measurement inputs to recording system • Combined
recording table for roll chart ( 32 m ) fanfold chart ( 16 m ) •
RS-485 interface •
2 limits per measuring channel •
Balancing
•
4 event markers
•
Can alternatively be used as event recorder with 10 event markers
•
6 measuring
channels •
Last point visible from the front •
Electrically isolated earth-free
measuring channels •
Process signals ranging from 0/4 ... 20 mA, 0 ... 1V •
Front panel dimensions: 144 mm x 144 mm, installation depth: 250 mm • Combination
plotter
for paper rolls ( 32 m ) or continuous fan-fold paper ( 16m ) •
RS 485 interface
