Harmonic-free PDPI control algorithm •
Seft-optimization for idealcontrol parameters •
Digital diaplay for actual value setpoint ( manipulating
factor,heating
current ) •
Setpoint can keyed in •
Control outputs can be shut down with a single keystroke •
Programmable limit values and setpoint limiting • Sensor
error display •
Heating current acquired with an external transformer • IP 65
protection at front panel •
Extermely small installation depth of only 50 mm
•
Harmonic-free PDPI control algorithm •
Seft-optimization for idealcontrol parameters •
Digital diaplay for actual value setpoint ( manipulating
factor,heating
current ) •
Setpoint can keyed in •
Control outputs can be shut down with a single keystroke •
Programmable limit values and setpoint limiting • Sensor
error display •
Heating current acquired with an external transformer • IP 65
protection at front panel •
Extermely small installation depth of only 50 mm Order options: •
Controller as two-position or three-position controller • Long (
12 to 120s ) medium ( 6 to 75 s )
or short ( 1 to 15 s ) time response • PT100
( 2-wire ) or direct current ( 5 mA, 20 mA ) measuring ranges • 1st
switching output: relay or transistor • 2
limit contacts ( mIN / MAX ) • Broken
sensor fuse, direct and reverse-acting •
Auxiliary voltages: 110VAC,120 V AC, 220 V
AC, 240 V AC
•
Temperature controller
for the direct connection of thermocouples
and resistance thermometer Pt100 •
Available as 2-setp and 3-step controller
with and without time response •
Compact housing, front panel dimension: 96 x 96 mm per DIN 43700 For installation to panel
switchboards, front panels etc. • Easy
operation, extensive standard function and few device variants • Two
keys each for function selection and value settings •
Replaces GTR 0218 •
Extermely small installation depth of only 50 mm
•
Temperature controller
for the direct connection of thermocouples
and resistance thermometer Pt100 as well as standard
signals •
Single-channel digital controller with microprocessor •
Available as 2-step, 3-step, continuous- action, step-action,
fixed value, differential or slave controller •
Compact housing, front panel dimensions: 96x96 mm •
Compact housing, front panel dimensions: 96 x96 mm per DIN 43700
For installation to control panels etc. •
Easy operation, extensive standard functions
and few device variants • Two
keys each for function selection and value settings
• Two
and three-step controller •
Universal input: thermocouple, PT100, linear ( mV,mA ) •
Universal alaem monitoring with actuation suppression •
Heating circuit monitoring •
Setpoint ramps for increases and decreases •
Soft start function Order options for
output auxiliary power:
2 relay outputs, 1 relay and one logic output, 2
logicoutputs
Auxiliary power: 100 to 240 V AC, 24V
AC/DC
•
Digital display for actual value and setpoint/regulated temperature
heating current •
Push-button manual operation • Relay
or transistor output •
Externally activated alternative setpoint •
Rising or falling setpoint ramp • Regulatedtemperature
is maintained in the event of sensor failure •
Heating circuit and heating current monitoring
For installation to control panels etc. •
One limit
contact with absolute/relative monitoring, start-up inhibit
make or break contact • Adaptable
to export markets: 230/110V and
°C
or F • CSA
certifition
The controller is equipped with the following fucntions, depending
upon order configuration: • Two
position, three position, step or continuous-action controller •
Sensor input for thermocouple types J,L,K,B,S,R,N amd PT 100
( 2/3-wire ) or standard signals: 0/2 .. 10V and 0/4 .. 20mA • Auxiliary
voltage: 24VAC,24VDC, 110VAC/230VAC
•
Digital display for actual value and setpoint/regulated temperature
heating current •
Push-button manual operation • Relay
or transistor output •
Externally activated alternative setpoint •
Rising or falling setpoint ramp • Regulatedtemperature
is maintained in the event of sensor failure •
Heating circuit and heating current monitoring • Two
limit contacts with absolute/relative monitoring, start-up inhibit,
make or break contact •
Adaptable to export markets: 230/110V and
°C
or F • CSA
certifition
Depending upon order configuration the controller is equipped with
the following characteristics: • Two
position, three position, step or continuous-action controller
• Differential or follw-up control with second input •
Sensor input for thermocouple types J,L,K,B,S,R,N amd PT 100
( 2/3-wire ) or standard signals: 0/2 .. 10V and 0/4 .. 20mA • Auxiliary
voltage: 24VAC,24VDC, 110VAC/230VAC
• PID
control algorithm •
SMART self-tuning •
Inputs:
Universal measurement inputs ( thermocouples, Pt100 standard
External setpoint
Heating circuit monitoring Logic inputs •
Outputs: relay, TRIAC, SSR,servomotor, logic outputs, standard
signals • Pro
tection: IP 65 and NEMA 4X •
Adaptable for export makets: Celsius/Fahrenheit
100V /240VAC ( 50/60 Hz ) or 24V AC/DC • Inter
face: isolated RS 485, MODBUS,JBUS •
Security code for operating functions •
Programer ( optional ) with 200 segments, up to 90 individual
programs, 9 combined programs, timer function
• External setpoint, rising and falling and equal percentage valves) •
Output with linearization ( quick opening and equal percentage
valves •
Heating current monitoring with external current transformer
• Power supplay for 2,3 or 4-wire transducers ( 24VDC )
• Split range
• Soft-start function
Optional: •
Controller with or without programmer
