Features •
2,4,6 or
12 direct universal: DC voltage, current and
thermocouples •
High speed storage capability: up to 8 samples per
second per
channel. •
Multiple storage media options: 3 1/2 1.4MB disk, or Compact
Flash up to 2 •
5.6 Brilliant TFT active matrix color or 5' monochrome display •
Intuitive Touchscreen Control with anti-glare coating. •
IP65
rated front panel. •
Standard IN enclosure: 144mm x 144mm bezel •
6 relay contact or solid state relay outputs/3 digital control input •
Parallel printer output •
Serial output options: RS232 or RS485. •
10BaseT Ethernet connection. •
Companion Software for unit configuration, communication, data
analysis, pi export to standard spreadsheet/database
applications.
DataChart 1250 Overview
• The
DC 1250 is a feature rich digital recording system offering
2 universally configurable isolated inputs for measuring DC voltage,
DC current, thermocouples RTD s as well as frequency
and pulse
input are all standard. Combining small package size with extreme
flexibility make the DataChart 1250 a powerful. vet
economical,
digital data recording system •
A
maximum sample storage rate of 100 samples per second can
be set for both channels allowing for capture of short
duration
precess signals anomalies points to be stored over long
periodes
of time. •
With intuitive operation, flexble input configuration and large
memory
capability the DAtaChart 1250 is a powerful,
compact digital recorder
